Electric Tankless Water Heater Installation Requirements

Updated August 2026 – This guide was expanded with clearer electrical, plumbing, sizing, location, permit, cost, and post-installation checks, including current SHiE Series requirements and a practical pre-installation checklist for homeowners and installers.

---

Electric tankless water heater installation requirements begin with the exact model manual, enough electrical service and panel capacity, and a suitable plumbing location. Whole-home electric units can draw far more power than a conventional tank heater, so the site should be approved before the heater is purchased. A licensed electrician should verify the electrical design, while a qualified plumber should confirm the water connections and local requirements. In this guide, we’ll walk through the checks that help homeowners plan a safe, code-compliant installation and avoid costly surprises.

Key Takeaways

• There is no universal breaker or wire size for every electric tankless water heater. Use the exact model’s current manual and equipment label.
• Confirm hot-water demand and electrical capacity before buying the heater. A model that meets demand may still exceed the home’s available service or panel capacity.
• Whole-home models may require multiple dedicated 240-volt circuits, open panel spaces, and an electrical service or panel upgrade.
• Plan the plumbing, mounting location, clearances, permits, inspections, and installer responsibilities along with the electrical work.
• Do not treat a generic installation diagram as a wiring plan. A licensed electrician should design and complete the electrical installation.

What Are the Installation Requirements for an Electric Tankless Water Heater?

The core requirements are a correctly sized heater; service and panel capacity for its full electrical load; the model-specified voltage, breaker count, breaker rating, and copper conductor size; a dry, accessible mounting location; compatible water connections; and any permits or inspections required locally. The current installation manual, rather than a generic diagram or another model’s specifications, is the controlling reference.

Electric tankless water heaters use heating elements while hot water is flowing, and that instantaneous demand can be substantial. The current Eccotemp SHiE Series, for example, uses 240-volt power and up to three dedicated circuits, depending on the model. That is why a former tank-heater circuit should never be assumed adequate.

This article is a planning and installer-handoff guide, not a wiring procedure. Have a qualified electrician complete the load calculation and electrical work, and use a licensed plumber where required. The installer should follow the manual, equipment label, locally adopted electrical and plumbing codes, and the authority having jurisdiction.

1. Confirm the Heater Is Sized for Your Hot-Water Demand

Electrical feasibility and hot-water performance must be checked together. Size an electric tankless heater by the peak flow needed at one time and the temperature rise between incoming water and the target outlet temperature. Gallons per minute (GPM) describes flow. Temperature rise describes how much heating the water needs. Colder incoming water reduces the flow a given kilowatt (kW) rating can heat to the same outlet temperature.

List the fixtures that may run together, estimate their combined demand, and compare that demand with the manufacturer’s flow-versus-temperature-rise data. Eccotemp’s tankless water heater sizing guidance explains the household-demand side. Then ask the electrician whether the panel can support the model that meets that demand. A smaller power setting may ease the electrical load, but it also reduces available heating output.

2. Have an Electrician Check Service and Panel Capacity

Ask a licensed electrician to complete a load calculation for the home, not just count empty breaker spaces. The review should include the incoming electrical service, the main panel rating, existing loads, available panel positions, the required number of dedicated circuits, the conductor route, and any locally required circuit protection or disconnecting means.

An existing electric tank water heater commonly uses a different circuit arrangement from a high-output tankless model. Reusing that circuit without checking the new equipment label and manual can lead to nuisance trips, reduced performance, or an unsafe installation. If the service or panel cannot support the selected model, the practical choices are an approved electrical upgrade, a lower-output model that still meets demand, or a different water-heating approach.

Understand Voltage, Amperage, Breakers, and Wire Size

Kilowatts measure electrical input. Amperes describe current. American Wire Gauge (AWG) identifies conductor size. Breakers protect a circuit; they are not selected from the heater’s marketing flow rate.

Power divided by voltage gives the approximate current for a resistive load. For perspective, 27,000 watts divided by 240 volts equals 112.5 amperes, which aligns with the SHiE-27’s 113-amp maximum in Eccotemp’s manual. This explains why a whole-home model may need several circuits. It is not a method for selecting breakers, conductors, grounding, or other protections; those are model- and code-specific decisions for the electrician.

Current Eccotemp SHiE Series Electrical Requirements

Eccotemp’s current SHiE Series manual, posted June 7, 2024, includes three electrical reference rows. Eccotemp’s live catalog currently lists the adjustable 11–27 kW SHiE-27. The table below transcribes the manual’s technical data. In the manual, each heating-control channel is labeled a Triac.

Model	Rated Power and Voltage	Maximum Amp Load	Required Breakers	Minimum Copper Conductors
SHiE-11	11 kW at 240 V	50 A	1 × 50 A	1 × 8 AWG
SHiE-18	18 kW at 240 V	75 A	2 × 40 A	2 × 8 AWG
SHiE-27	27 kW at 240 V	113 A	3 × 40 A	3 × 8 AWG

These specifications apply to the manual’s listed SHiE configurations, not to every electric tankless heater. Product availability and configuration can change. Check the live product listing, current manual, and equipment label at the time of installation, and have the electrician confirm the final design against local code.

The SHiE manual also describes an in-app Power Limit Tuner that can reduce the maximum current assigned to each Triac. Treat that as a performance setting, not permission to improvise a circuit. Reduced power can reduce available hot-water output, and a licensed electrician must approve the circuit arrangement. Use the model’s full-rated requirements unless the current manual and the electrician support a different approved configuration.

3. Plan the Plumbing and Water Conditions

The installer should verify the cold-water inlet and hot-water outlet size, pipe material, available water pressure, isolation or shutoff valves, and any pressure-control or relief components required by the manual or local plumbing code. For the current SHiE Series, the manual lists 3/4-inch National Pipe Thread (NPT) water connections and a maximum inlet pressure of 150 pounds per square inch (PSI).

Plan enough access to inspect connections and service the heater later. In hard-water areas, ask what water-quality treatment and descaling schedule the manufacturer recommends. The heater should be fully plumbed, filled, purged of air, and checked for leaks before electrical power is applied; energizing dry heating elements can damage the unit.

A nearby cold-water shutoff helps with service. Whether the installation also needs a drain pan, leak detection, pressure-reducing equipment, a relief device, or other components depends on the model, location, plumbing system, and locally adopted code. The plumber and authority having jurisdiction should make that determination.

4. Choose an Approved Indoor Location

An all-electric tankless heater does not need a combustion vent, but it still needs an approved mounting location. The current SHiE manual specifies indoor, permanent, vertical installation and recommends at least 6 inches of clearance on all sides. Another model may have different requirements, so its manual controls.

Choose a dry location protected from freezing and accidental water spray. The wall must support the unit, and the installer needs room to connect the electrical circuits and water lines without sharp bends or strained fittings. Keep the controls and service points accessible rather than boxing in the heater after installation.

Shorter hot-water piping can reduce wait time and heat loss, but the shortest pipe route is not always the best overall location. The electrician and plumber should also consider conductor routing, service access, leak consequences, and any local clearance or protection requirements.

5. Check Permits, Codes, and Installer Roles

Electrical and plumbing rules vary by jurisdiction because local authorities adopt and amend codes on their own schedules. Before purchasing the heater, ask the local building department or licensed installer whether the project needs electrical or plumbing permits, plan review, an inspection, or an electrical service upgrade approval.

A typical division of responsibility looks like this:

• The electrician verifies service and panel capacity, performs the load calculation, designs the dedicated circuits, and installs the breakers, copper conductors, grounding, disconnecting means, and required circuit protection.
• The plumber verifies pipe sizing, water pressure, valves, pressure-control or relief requirements, leak protection, and startup water flow.
• The responsible permit holder schedules inspections and supplies the homeowner with approvals. If one contractor handles the full project, confirm that the contractor’s licensing covers both scopes.

Use Eccotemp’s broader tankless water heater installation checklist for non-electrical preparation that applies across fuel types. For this electric installation, the model manual and local professionals remain the final authorities.

What Affects Electric Tankless Water Heater Installation Cost?

The heater price is only one part of the project. Installation cost depends heavily on the home’s existing electrical system and the distance between the panel, heater, and plumbing connections. The largest variables can include:

• Electrical service, main-panel, or subpanel upgrades
• The number and length of new dedicated circuits
• Breakers, copper conductors, conduit, disconnects, and required circuit protection
• Plumbing rerouting, valves, pressure-control components, and leak protection
• Wall preparation, access work, and removal or disposal of the old heater
• Permit, plan-review, and inspection fees
• Labor rates and whether electrical and plumbing contractors must coordinate separate visits

Ask for a line-item quote that identifies the exact model, included electrical capacity work, plumbing work, permits, startup testing, and any exclusions. A low heater-only price does not reveal whether the site can support the product.

Pre-Installation Checklist to Give Your Installer

Before ordering the heater, confirm that the installer has reviewed:

• The exact model number, equipment label, and current installation manual
• Peak simultaneous hot-water demand and the required temperature rise
• The model’s flow rating at that temperature rise instead of relying on its maximum advertised GPM
• The electrical service and panel load calculation
• Required dedicated circuits, breaker ratings, copper conductor sizes, panel positions, grounding, disconnects, and locally required protection
• Mounting orientation, clearances, wall support, freezing protection, and service access
• Water-connection sizes, pressure, shutoffs, and any required pressure-control, relief, drainage, or leak-protection components
• Permit, inspection, old-equipment removal, startup testing, and warranty-document responsibilities

This review creates a useful go/no-go decision before purchase: the selected model must meet the hot-water demand, and the property must safely support the model’s electrical and plumbing requirements.

What to Confirm After Installation

Before the contractor leaves, verify that the installed model matches the quote and permit, the circuits are labeled, the water connections are dry, and the heater delivers stable temperature at the planned flow. Ask the installer to confirm that air was purged before energizing the unit and that grounding, circuit protection, water pressure, and required inspections were completed.

Keep the current manual, permit and inspection records, contractor information, model and serial number, and startup settings. These records make future service and warranty questions easier to resolve. Do not open the electrical enclosure or change the circuit arrangement yourself; contact the installer or Eccotemp support if performance does not match the approved design.

Choose the Model Only After the Site Is Approved

Once the sizing and site review are complete, compare Eccotemp’s current electric tankless water heaters and recheck the manual for the exact model under consideration. Site approval first helps prevent buying a heater that the home cannot power or that will not meet the required hot-water demand.

Frequently Asked Questions

What Size Breaker Do I Need for an Electric Tankless Water Heater?

Breaker size depends on the exact model and circuit arrangement. Use the installation manual and have a licensed electrician verify panel capacity, wiring, and local code requirements.

Does an Electric Tankless Water Heater Need Venting?

No combustion vent is needed for an all-electric tankless heater. The unit still needs an approved indoor location, required clearances, plumbing access, and service space.

Can I Replace a Tank Water Heater Without Upgrading My Electrical Panel?

Sometimes, but do not assume the existing circuit is sufficient. An electrician must compare the model’s full load with panel capacity and available dedicated circuits.
